Particularly suitable for voluminous light-weight cargoes (e.g. fruit, flowers, ferns).

  • Especially for cargo which needs constant temperature above or below freezing point.
  • Controlled fresh-air supply is possible.
  • Walls in “sandwich-construction” with Polyurethane foam in order to provide maximum insulation.
  • The reefer unit is a compact-design compressor unit with air-cooled condenser. It switches automatically from cooling to heating-operation (and vice-versa), if a change of the outside temperatures makes it necessary.
  • Possible voltages: 380 V/50 Hz to 460 V/60 Hz.
  • Permissible temperature setting: +25°C to –25°C (+77°F to –13°F)
  • The set temperature can be kept as long as the difference between the average outside temperature and cargo temperature does not exceed the following limits:
  • for heating 42°C (76°F)
  • for cooling 60°C (108°F)





Außenmaße: (L x B x H) 12,190 mm x 2.440 mm x 2,890 mm

Innenmaße: (L x B x H)  11.580 mm x 2,300 mm x 2,550 mm

Türmaße: (B x H) 2,300 mm x 2,550 mm

Max.Gewicht:  30,480kg

Max.Zuladung: 28,500kg

Tara:  3,990kg

Volumen: 66,5 m3
