40′ FLAT RACK CONTAINER



Flatracks consist of a floor structure with a high loading capacity composed of a steel frame and a softwood floor and two end walls, which may either be fixed or collapsible. The end walls are stable enough to allow cargo securing means to be attached and several flatracks to be stacked on top of one another.

40′ flatracks have gooseneck tunnels at each end. In addition, they are sometimes equipped with lashing winches with 2 metric ton lashing belts

For transport of certain cargoes, flatracks may be provided with stanchions.



Construction:   Full corten steel



Dimensions:

External:

Length base bottom casting : 12,190 mm

Width base bottom casting:  2,440 mm

Height end frame erected:  2,900 mm

Stack height:  2,900 mm



Internal:

Length between corner posts : 12,000 mm

Width over bottom side rail:  2,300 mm

Width between corner posts:  2,220 mm

Stack height:  2,660mm



Max. Gross Weight: 30,000kg

Max. Payload:  25,000kg

Tare weight:  5,480kg
