МОБИЛЬНЫЕ РАМПЫ
Mobile Hydraulic Dock Ramp is a special auxiliary equipment for loading and unloading of
goods rapidly. Its height adjustment feature allows forklifts and other moving vehicles to
enter into the truck directly and handle the goods.
Characteristic
The dock ramp is mobile and controlled by manual hydraulic system, so only one person
could operate it conveniently. It enables you to reduce the amount of labor and raise
working efficiency.
Спецификация :
Description | 6ton & 8ton | 10ton |
Table size | 10500x2000mm | 10500x2000mm |
Грузоподъемность: | 6000 — 8000kg | 10000kg |
Lifting Height | 0.9-1.7m | 0.9-1.7m |
Elevation Degree | ≤13° | ≤13° |
Self Weight | 2300kg | 2800kg |
Plate | 4mm steel plate + 6mm diamond mesh | 4mm steel plate + 6mm diamond mesh |
Bridge Girder Material | 160x80x5mmx4pc Rectangular tube, Q235 | 200x100x6mmx4pc Rectangular tube, Q235 |
Secondary Beam | 120x60x5mm rectangular tube | 120x60x5mm rectangular tube |
Pin Roll | #45 tempered | #45 tempered |
Hydro-Cylinder | HSGG45/80-295/605-2 (Hebei Hengyu) | HSG90-2 (Hebei Hengyu) |
Power Supply | handlance | handlance |
Hydraulic Hose | high pressure rubber tube,1-ö16-1 | high pressure rubber tube,1-φ16-1 |
Pressure | ≤16Mpa | ≤16Mpa |
Hydraulic Oil | Sinopec Great Wall #32, high pressure hydraulic oil | Sinopec Great Wall #32, high pressure hydraulic oil |
Sealing Ring | VALQUA | VALQUA |
Guardrail | 50x50x3mm rectangular tube, 50x50x4mm angle steel tube | 50x50x3mm rectangular tube, 50x50x4mm angle steel tube |
Tire | 600-9x2pc, pneumatic tire | 700-9x2pc, pneumatic tire |
Warranty:
- User-friendly English manual for machine using and maintenance.
- 1 (One) year warranty for whole machine without man-made fault;
